Presets

Movie, Music, Sports, Neutral, AMBEO off, on (Light, Standard, Boost)

Number of channels

5.1.4

Speaker type

• 6x 4″ longthrow woofer, cellulose sandwich cone
• 5x 1″ tweeter, aluminium dome tweeter
• 2x 3.5″ fullrange driver (top-firing)

Total number of speakers

13

Frequency response

30 Hz to 20 kHz (-3 dB)

Weight

approx. 18.5 kg

Dimensions

• approx. 126.5 x 13.5 x 17.1 cm incl. feet
• approx. 126.5 x 12.5 x 17.1 cm w/o feet

Temperature Range

operation: +10 C to +40 C

storage: -20 C to +70 C

Power consumption

250W (Sinus), 500W (Peak) Standby Power Consumption: ECO Standby ON = 1.9W, ECO Standby OFF = 5.5W

Voltage

100 240 V~ 50/60 Hz

Power plug

Country specific

App support

Sennheiser Smart Control App

Inputs

• 3x HDMI In (v.2.0a), 1x HDMI Out (v.2.1 eARC)
• 1x Optical In
• 1x AUX In (Stereo RCA)
• 1x USB (for Service/Update)
• 1x Ethernet
• 1x Subwoofer Pre-Out (Mono-RCA, max. 2V)
• 1x Mic Input (2.5mm jack)
• Bluetooth
• Google Chromecast
• Media (UPnP)

WiFi Standard

IEEE 802.11 a/b/g/n/ac

Supported audio/surround formats

• LPCM 2 Channel, LPCM 5.1 Channel, LPCM 7.1 Channel
• Dolby Digital, Dolby Digital Plus
• Dolby True HD
• Dolby Atmos – Dolby TrueHD, Dolby Atmos – Dolby Digital Plus
• DTS
• DTS-ES Discrete 6.1, DTS-ES Matrix 6.1
• DTS 96/24
• DTS-HD LBR
• DTS:X
• DSD, MPEG-H
