Rotel RA-1572MKII

Description

RA-1572MKII

The RA-1572MKII Integrated Amplifier brings your music to life with exceptional fidelity delivering 120 Watts of Class AB output into 8 ohms with deep, controlled bass energy.The audiophile grade DAC, analog, digital, aptXTMand AAC Bluetooth, PC-USB supporting MQA and Moving Magnet Phono stage ensure exceptional detail and immersive soundstage.

• Certified Roon Tested
• Supports MQA and MQA Studio
• 2 x 200 Watts of robust Class AB power, 4 ohms
• Moving magnet phono input for turntable connection
• Wireless aptX and AAC Bluetooth

The RA-1572MKII Integrated Amplifier is an essential componentfor music lovers leveraging the best of Rotels analog and digitaltechnologies bringing music to life with exceptional fidelity.The role of an integrated amplifier continues to evolve with theRA-1572MKII optimized in every aspect including the poweramplifier delivering 120 Watts of robust Class AB output into 8ohms, audio circuit design innovations, premium audiophileDigital to Analog Converter and a full complement of sourceinputs.

As typical of Rotel amplifiers, the RA-1572MKII utilizes anin-house manufactured oversized toroidal transformer. Thetoroidal transformers shape helps prevent stray radiationpatterns from corrupting audio signals as they pass throughadjacent circuits. The transformer feeds a bank of 4 low ESR,high efficiency, T-Network slit-foil storage capacitors for deep,controlled bass energy.

The RA-1572MKII support digital sources utilizing a TexasInstruments 32-bit/384kHz DAC with critically tuned output filtercircuits rendering even the most subtle detail. The preamplifiercircuits and linear amplifier gain stages have been customengineered ensuring natural detail, agility and an immersivesoundstage. Analog, digital, PC-USB supporting MQA, aptX andAAC wireless Bluetooth streaming, XLR Balanced and MovingMagnet Phono stage inputs ensures connection to your favoritesources.

The RA-1572MKII is certified Roon Tested delivering the bestexperience using Roon software so you can just enjoy the music.

The front panel includes a status display, source and volumecontrols, Speaker A-B selection for Zone 2, and 3.5mmheadphone jack. Ethernet and RS232 connections allowseamless integration with control systems and softwareupdates.

Engineered with care.

DIMENSIONS (W H D)431 144 358mm
17″ 5.7″ 14.1″FRONT PANEL HEIGHT3U / 132.6mm (5.25″)POWER REQUIREMENTS120V, 60HzPOWER CONSUMPTION400WSTANDBY POWER CONSUMPTION<0.5WNET WEIGHT13.63kg (30.05lbs.)BTU RATING(4, 1/8th power)810 BTU/h

MAXIMUMPOWER OUTPUT200W/Ch (4)CONTINUOUS POWER OUTPUT120W/Ch (8)TOTAL HARMONIC DISTORTION(THD)<0.018%FREQUENCY RESPONSE
Line Level Inputs:10Hz – 100kHz, 0.5dBDigital Inputs:10Hz – 90kHz, 2dBPhono Input:20Hz – 20kHz, 0.5dBS/N RATIO(IHF “A” Weighted)
Line Level Inputs: 100dBDigital Inputs: 100dBPhono Input: 80dB
INTERMODULATION DISTORTION(60Hz:7kHz, 4:1)<0.03%DAMPING FACTOR300INPUT SENSITIVITYLine Level Inputs (RCA): 270mVLine Level Inputs (XLR): 440mVDigital Inputs: 0 dBFsPhono Input (MM): 2.1mVINPUT IMPEDANCELine Level Inputs (RCA): 100kLine Level Inputs (XLR): 100kDigital Inputs: 75Phono Input (MM): 47kINPUT OVERLOADLine Level Inputs (RCA): 4VLine Level Inputs (XLR): 5.5VPhono Input: 32mVPREOUT LEVEL1.5V
OUTPUT IMPEDANCE470COAX/OPTICALDIGITAL INPUT SIGNALSLPCM (Up to24-bit/192kHz)PC-USBUSB Audio Class 1 (up to 24-bit/192kHz)
USB Audio Class 2 (up to 32-bit/384kHz)**Driver installation requiredMQA and MQA Studio(up to 24-bit/384kHz )Roon Tested
