Description
Zpre3 Two Channel Zone Preamplifier
- Front panel LCD function display with dimming
- Automatic turn on volume memory
- Favorite volume memory with remote control button
- 2-way RS232 w/ exact volume control & feedback
- Discrete commands for all functions
- Rename inputs to match connected source
- 5 audio inputs including a front panel Aux input
- Bypass input integrates easily w/ a Sonos Connect etc.
- Bass, treble and balance adjustments by remote control
- Variable and fixed stereo outputs
- Variable and fixed mono/subwoofer outputs
- 12dB auto gain offset at front panel AUX to match levels of other sources
- 12V trigger output and rear panel IR input
Specifications
| Frequency Response | 10 Hz – 40 kHz, +0/-0.5 dB |
|---|---|
| Input Impedance | 24k |
| Dimensions | Width: 8.5″ (220 mm) Depth: 10″ (254 mm) Depth: 12″ (305 mm) with AC cord and cables connected Height, with feet: 2″ (51 mm) Height, without feet: 1.75″ (45 mm), 1U |
| Total Harmonic Distortion | (20 Hz – 20 kHz) <0.015% |
| Output Impedance | 470 |
| Interchannel Crosstalk | 62 dB at 20 kHz |
| S/N Ratio | >100 dB, input shorted, IHF A-weighted >90 dB, input shorted, unweighted |
| Weight | Net: 4.0 lbs (1.8 kg) Shipping: 7.0 lbs (3.1 kg) |
| Input Sensitivity | 250 mV = 1 V output Total gain = 12dB (volume set to 100) Unity Gain = Volume set to 88 Maximum Output: 3.5 V |
| DC Trigger Output | 12Vdc, 50ma |
| AC Power Requirement | 5 Watts powered on 0.5 Watts in standby 100 – 250 VAC 50/60 Hz |
| Rack Mount Accessory | May be Purchased Separately |
