Description
Compact, Powerful Sound in a Smaller Package
Our most compact headed model brings all the technical advantages of a dedicated midrange enclosure the Turbine Head, with its decoupled midrange cone to a smaller footprint thats easily accommodated in any home. With advanced technology and sleek design, this model offers exceptional sound quality without taking up much space.
Key Features
- Diamond tweeter for superior high-frequency performance
- Solid body Tweeter-on-Top for optimal sound dispersion
- Continuum cone FST for precise and natural midrange sound
- Matrix and Anti-Resonance plug for enhanced clarity
- Biomimetic Suspension for improved damping and performance
- Turbine Head for a decoupled midrange cone, improving sound definition
- Aerofoil cone bass units for deep, powerful bass
- Flowport for reduced distortion and increased airflow
- Elegant finishes available in Gloss Black, White, Satin Rosenut, and Satin Walnut
Technical Specifications
| Specification | Details |
|---|---|
| Size & Weight | Net weight: 62.15kg (137 lb) |
| Dimensions | Height: 1165mm (45.9 in), Width: 357mm (14.1 in), Depth: 511mm (20.1 in) |
| Description | 3-way vented-box system |
| Drive Units | 1x 25mm (1in) Diamond dome high-frequency, 1x 130mm (5in) Continuum cone FST midrange, 2x 180mm (7in) Aerofoil cone bass units |
| Frequency Range | 16Hz to 35kHz |
| Frequency Response | 19Hz to 28kHz (+/-3dB from reference axis) |
| Sensitivity | 90dB (on axis at 2.83Vrms at 1m) |
| Harmonic Distortion | 2nd and 3rd harmonics (90dB, 1m on axis) < 1% (80Hz 20kHz), < 0.3% (100Hz 20kHz) |
| Nominal Impedance | 8 (minimum 3.0) |
| Recommended Amplifier Power | 50W 500W into 8 on unclipped programme |
| Max Recommended Cable Impedance | 0.1 |
| Finishes | Gloss Black, White, Satin Rosenut, Satin Walnut |
| Grille Finishes | Black, Grey |
